Description
This 12″ jointer offers big capacity and performance in a machine that is loaded with features. Large center-mounted fence assembly adjusts easily via rack and pinion system with ram lock. Preset stops on the fence body allow for fast angle set-up at 45° in and out, and a positive stop for perfect 90° angles.
The parallelogram design keeps the table in close proximity to the cutterhead for improved finish and allows for a fast depth of cut adjustment. This design also ensures the tables remain perfectly parallel even after years of tough duty. Choose either the standard three-knife cutterhead or the solid steel Helical cutterhead. The helical system makes fast work of knife changing and never needs adjustment.
Features
- Large 12″ x 84″ precision ground cast iron table surface for heavy-duty work
- Parallelogram design for close table-to-cutterhead proximity and fast depth of cut adjustments
- Rack and pinion adjustable cast iron fence assembly for smooth fence positioning without play
- Straight knife cutterhead with 3 high speed steel knives create a clean cut
- Table “lips” on both sides of cutterhead aid in noise reduction
Specs
Cuts Per Minute:15,000
Cutterhead Speed (RPM):5,000
Cutting Capacity (W x D):11-3/4″ x 3/4″
Dust Collection Minimum CFM Required (CFM):800
Dust Port Outside Diameter:4″
Motor Phase:1
Motor Power (HP):3
Motor Voltage (V.):230
Number of Knives:3
Prewired Voltage (V.):230
Recommended Circuit Size (Amps.):30
Type of Cutterhead:Straight Knife
SKU: PM9-1791241
