StarTech SV231USB 2 Port Professional USB KVM Switch Kit with Cables

SV231USB – Overview

StarTech SV231USB2 Port Professional USB KVM Switch Kit with Cables offers simple control of two Mac or PC computers from a single monitor/display and USB peripheral set (keyboard, mouse).

The 2 Port KVM switch includes 2 USB KVM cables, providing a complete out-of-the-box KVM solution saving you time and money. An integrated 3 port USB hub allows you to share connected USB peripherals between connected computers as though they were connected directly. A compact form factor design and rear-port connections to master and slave computers minimizes disruption to your workspace.

A cross-platform solution, this OS independent KVM switch supports high resolution applications up to 1920×1440, and provides a smooth operating experience when controlling mixed (Windows/Mac/Linux) environments.

ApplicationsDual system control for a single workstations increasing user productivity in the officeProvide centralized control for multiple high-res Digital Signage server controlGreat for manufacturing line computer control, simplifying access to multiple systems

• Features:

  • Control 2 computers from one USB keyboard/mouse/monitor
  • Share 3 different USB peripherals using the integrated hub
  • High 1920×1440 resolution capability
  • Front panel push buttons for easy computer selection
  • OS independent – no software or drivers required
  • Supports keyboard and mouse plug and play
  • Selectable auto scan time interval
  • Supports DDC2B VGA monitors
  • USB self-power operation

• Specifications:

  • Hardware
  • Audio: No
  • Cables Included: Yes
  • Daisy-Chain: No
  • KVM Ports: 2
  • Number of Monitors Supported: 1
  • PC Interface: USB
  • PC Video Type: VGA
  • Rack-Mountable: No
  • U Height: 1U
    Performance
  • Auto Scan: 3, 8, 15 & 30 seconds
  • DVI Support: No
  • Hot-Key Selection: No
  • IP Control: No
  • Maximum Analog Resolutions: 1920 x 1440
  • Maximum Cable Length: 15 ft [4.6 m]
  • Maximum Number of Users: 1
  • MTBF: 111,000 Hours
  • On-Screen Display: No
  • Port Selection Support: Push Button
    Console Interface Connectors
  • 1 – VGA (15 pin, High Density D-Sub) Female
  • 3 – USB Type-A (4 pin) USB 2.0 Female
    Host Connectors
  • 2 – USB B (4 pin) Female
  • 2 – VGA (15 pin, High Density D-Sub) Male
    Software
  • OS Compatibility: OS independent; No software or drivers required
    Special Notes / Requirements
  • Note: This KVM supports the use of VGA cables up to 100ft in length – active extension required for USB to achieve that distance
    Power
  • Center Tip Polarity: Positive
  • Input Current: 0.4A
  • Input Voltage: 100 – 240 AC
  • Output Current: 2A
  • Output Voltage: 5 DC
  • Plug Type: N
  • Power Consumption (In Watts): 10
  • Power Source: AC Adapter Included
    Physical Characteristics
  • Cable Length: 6 ft [1.8 m]
  • Color: Black
  • Material: Steel
  • Product Height: 1.6 in [4 cm]
  • Product Length: 4.9 in [12.4 cm]
  • Product Width: 2.8 in [70 mm]
  • Weight of Product: 14.9 oz [421 g]
    Packaging Information
  • Package Height: 3.6 in [92 mm]
  • Package Length: 9.4 in [23.8 cm]
  • Package Width: 7.4 in [18.7 cm]
  • Shipping (Package) Weight: 2.5 lb [1.1 kg]

• Item Includes:

  • 1x2 Port USB KVM Switch
  • 2x2 IN 1 USB/VGA Cables
  • 1xPower Adapter
  • 1xManual

• Warranty:

  • 3-year

• GTIN:

  0065030789196
