Sale!
Planer Holzprofi Maker ADM410 spiral shaft 400V

Planer Holzprofi Maker ADM410 spiral shaft 400V

Original price was: $4,452.59.Current price is: $199.99.

SKU: HP-M1-ADM410SPIRAL Category: Tag:

Description

Features & benefits

  • Spiral planing shaft:The four-row spiral planing shaft with angled blades enables a pulling cut, which ensures excellent surface quality.
  • Cast iron tables:The robust cast iron tables offer stability and precision during planing.
  • Mechanical digital display:Enables exact settings for precise work results.
  • Swivelling aluminium fence:Offers flexibility at different working angles and supports precise dressing.
  • Switchable feed:Allows the feed speed to be adapted to different types of wood and requirements.
  • Noise reduction:The machine is designed for quiet operation, which increases working comfort.
  • Safety features:Equipped with motor protection, motor brake and zero voltage release for safe working.

These features make the ADM410 an excellent choice for precise and efficient planing work in professional woodworking.

Planer Holzprofi Maker ADM410 spiral shaft 400V
Technical data
Motor power output S6 3.8 kW (3 kW-S1)
Planing knives 72, 4 rows
Knife dimensions 15 x 15 x 2.5 mm
Shaft diameter 95 mm
Planing width 400 mm
Planer table length 1660 mm
Passage height 230 mm
Feed speed 6 m/min
Suction diameter 100 mm
Thicknessing table 410 x 600 mm
Voltage 400 V
Max. chip removal (depending on board width and type of wood) 3-5 mm
Weight approx. 334 kg
