Description
The Laguna Pro Shaper combines a precision shaper with features normally found only in much higher priced machines. For starters, the table measures an impressive 31″ x 39″ and is predrilled to accept most power feeders. The fence has a precision micro-adjustment that is aligned by a solid steel bar. Each full revolution of the turn handle gives an exact 1/16 adjustment to the fence.
Inside you will find a heavy-duty 5HP 220 volt single-phase motor. It offers 3 speeds with a unique quick change poly-groove belt system rather than the traditional V-belt. Digital readout is standard for the spindle height. The Pro Shaper is also equipped with a reversing switch and all controls are mounted with an easy access panel.
The fit and finish on this machine are top notch and even includes a wheel kit built right into the base. The Laguna Pro Shaper is designed to give you years of trouble-free performance without breaking the bank.
All Laguna Tools woodworking machinery carry a 2-year warranty. Must register machine within 30 days of purchase.
Also available in 7.5hp & 3-phase.
Features
- Heavy-duty precision fence
- Rack and pinion macro adjustment
- Quick-release belt change
- 6 step spindle exchange
- Dual dust ports
Specs
Motor:5HP 1 phase 220V 60 HZ
Table size:39-5/16″ x 31-7/16″ x 3-1/2″
Spindle travel:4″
Spindle Sizes:3/4″ and 1-1/4″
Capacity Under Nut:6 (for 1-1/4″ ) & 4 (for 3/4″ )
Router Collets:1/4″ and 1/2″
Spindle speeds:5,000 / 7,000 / 10,000 RPM
Table Opening Diameter:7-5/16″
Digital Readout:Standard
Direction:Forward/Reversing Switch
Fence:Micro Adjustment
Weight (Net/Ship):640/720 Lbs.
Video
SKU: MSHAP5010-0130
