Description
Specifications:
|
Construction:
|
Heavy-duty commercial lockset, solid cast exterior housing, solid cast levers |
|
Locking Device:
|
STD Mortise 1¼” (32 mm) face plate no deadbolt (non-handed) |
|
Numeric Keypad:
|
Vandal resistant, solid metal pushbuttons |
|
Handing:
|
Non-handed, pre-assembled for left-hand door installation, easily changed in the field |
|
Finish:
|
Satin Chrome 626 |
|
Key Override:
|
Best and Equivalents (6 or 7-pin length); cylinder not included(lever preps are not interchangeable) |
|
Backset:
|
2¾” (70 mm) backset |
|
Latch:
|
¾” (19 mm) latch, 1″ (25 mm) |
|
Minimum Stile Recommended:
|
5″ (127 mm)
|
|
Door Preparation:
|
ASA 86 door preparation with three additional through bore holes |
|
Door Thickness:
|
1¾” (44 mm) to 2¼” (57 mm); pre-assembled to accommodate doors 1¾” (44 mm) to 2⅛” (54 mm) |
|
Accessibility Standard:
|
Americans with Disabilities Act (ADA)
|
|
Certification:
|
ANSI/BHMA Grade 1 Certified
|
|
Fire Rating:
|
UL 10C fire rated
|
|
Warranty:
|
3 years manufacturer warranty
|
Downloads:
- Installation Guide
- Spec Sheet
Return Policy: We do not accept returns on unsealed products. In order to return a defective item a support ticket is needed. To receive a ticket, please contact DORMA KABA directly at 1-800-849-8324 or visit their support page here. Once you have the ticket contact UHS Hardware for the return.
