Blonder Tongue AP-60-860A Agile Digital/Analog Processor w/ EAS

AP-60-860A – Overview

The Blonder Tongue AP-60-860A(Agile Digital/Analog Processor) operates in one of the three following modes: Mode 1: Analog Heterodyne Processor (Analog RF IN &gt Analog RF OUT) Mode 2: Digital Heterodyne Processor (QAM IN &gt QAM OUT) Mode 3: Digital-to-Analog Processor (8VSB or QAM IN &gt Analog RF OUT)

• Features:

  • As an agile analog heterodyne processor: accepts one Analog RF input (CATV sub-band channels T7-T13, CATV standard channels 2-135, VHF channels 2-13, and UHF channels 14-69) and delivers one Analog RF output (CATV standard channels 2-135)
  • As an agile digital heterodyne processor: accepts one Digital Cable QAM input (CATV sub-band channels T7-T13, and CATV standard channels 2-135) and delivers one Digital Cable QAM output (CATV standard channels 2-135)
  • As an agile digital-to-analog processor: accepts one Digital Off-air 8VSB or Digital Cable QAM input (CATV standard channels 2-135,VHF channels 2-13, and UHF channels 14-69) and delivers one Analog RF output (CATV standard channels 2-135)
  • Equipped with EAS interface which can also be used as an IF (Intermediate Frequency) input
  • Supports Closed Captioning (EIA-608)
